Pontiac Vibe I (2002-2004) remote control mirror switch Wiring diagram
This page shows the only wiring diagram for the component.remote control mirror switch, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote control mirror switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CIG FUSE
GRY WIRE
HOT IN RUN OR START
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LEFT INST- RUMENT PANEL JUNCTION BLOCK
LEFT OUTSIDE REAR VIEW MIRROR
LEFT RIGHT
LT GRN WIRE
MIRROR SELECT SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT INSTRU- MENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RIGHT LEFT
RIGHT OUTSIDE REAR VIEW MIRROR
SP 200 (UNDER LEFT SIDE OF DASH)
UP DOWN
WHT WIRE
