Pontiac Vibe I (2002-2004) rear dome lamp wiring diagram
This page shows the only wiring diagram for the component.rear dome lamp, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear dome lamp wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
DIODE
DOME FUSE
FRONT DOME LAMP
GLASS HATCH COURTESY SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL LAMP DIMMER
LEFT FRONT COURTESY SWITCH
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LEFT REAR COURTESY SWITCH
MAP LAMP (W/O SUNROOF)
MULTIFUNCTION ALARM MODULE
POWER TOPS SYSTEM
REAR DOME LAMP
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT COURTESY SWITCH
RIGHT REAR COURTESY SWITCH
SUNROOF SWITCH ASSEMBLY
TAILGATE COURTESY SWITCH
THEFT DETERRENT MODULE (OPTIONAL) (BEHIND RIGHT SIDE OF DASH)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ POWER DOOR LOCKS
W/O POWER DOOR LOCKS
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Courtesy lamps circuit -> REAR DOME LAMP
