Pontiac Vibe I (2002-2004) power fuse Wiring diagrams
This page contains all the electrical diagrams for the component. power fuse, in which he is found in the car Pontiac Vibe I (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power fuse (1 of 3)
115 VOLT POWER OUTLET
115 VOLT POWER OUTLET SWITCH
ACCESSORY AC/DC POWER CONTROL MODULE (UNDER DRIVER'S SEAT)
AM 1 FUSE
BLK WIRE
BLU WIRE
CENTER CONSOLE REAR POWER OUTLET
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LAMPS CONTROL MODULE THEFT DETERENT MODULE (W/ THEFT DETERENT)
DOOR FUSE
ECU-B FUSE
FROM ALT FUSE (DIAGRAM 2 OF 4)
FROM RIGHT INSTRUMENT PANEL JUNCTION BLOCK (DIAGRAM 2 OF 4)
FROM RIGHT INSTRUMENT PANEL JUNCTION BLOCK (DIAGRAM 4 OF 4)
FUSE
GLASS BREAKAGE SENSOR (W/ THEFT DETERENT)
GRN WIRE
GRY WIRE
ILLUM LAMP
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
INV FUSE
INV RELAY
LEFT FRONT POWER WINDOW SWITCH
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LEFT REAR POWER WINDOW SWITCH
MULTI- FUCTION ALARM MODULE
ODB FUSE
P/POINT FUSE
P/POINT RELAY
P/W RELAY
POWER FUSE
RED WIRE
RED/WHT WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RIGHT REAR POWER WINDOW SWITCH RIGHT FRONT POWER WINDOW SWITCH
STOP FUSE
STOP LAMP SWITCH
SUN ROOF RELAY
TAIL FUSE
TAIL RELAY
TO IGNITION SWITCH (DIAGRAM 4 OF 4)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> POWER FUSE
Wiring diagram power fuse (2 of 3)
BLK WIRE
BLU WIRE
DOME FUSE
GAUGE FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
MAP LAMPS
MOON ROOF CONTROL RELAY (CENTER OF WINDSHIELD HEADER)
P/W RELAY
POWER FUSE
RED WIRE
SLIDE CLOSE OPEN
SP 200 (UNDER LEFT SIDE OF DASH)
SP 201 (BEHIND RIGHT BODY HINGE PILLAR TRIM PANEL)
SUNROOF LIMIT SWITCH NO 1
SUNROOF LIMIT SWITCH NO 2
SUNROOF MOTOR
TILT DOWN UP
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT, MOUNTED TO INNER FENDER)
WHT WIRE
Go to component -> Power top/sunroof circuit -> POWER FUSE
Wiring diagram power fuse (3 of 3)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
DOOR LOCKS SYSTEM
DOWN
DOWN OR DOWN/ AUTO
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LEFT FRONT DOOR SWITCH
LEFT FRONT WINDOW MOTOR
LEFT FRONT WINDOW SWITCH
LEFT INSTRU- MENT PANEL JUNCTION BLOCK
LEFT REAR
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LOCK
P/W RELAY
POWER FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT FRONT
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
SP 200 (UNDER LEFT SIDE OF DASH)
SP 201 (BEHIND RIGHT BODY HINGE PILLAR TRIM PANEL)
UNLOCK
UP DOWN WINDOW SWITCH
UP LEFT FRONT WINDOW SWITCH
UP WINDOW SWITCH
WHT/BLK WIRE
WINDOW LOCK SWITCH
YEL WIRE
Go to component -> Power windows circuit -> POWER FUSE
