Pontiac Vibe I (2002-2004) passenger seat belt warning lamp Wiring diagrams
This page contains all the electrical diagrams for the component. passenger seat belt warning lamp, in which he is found in the car Pontiac Vibe I (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger seat belt warning lamp (1 of 2)
ABS NO 1 FUSE
ABS NO. 2 FUSE
AC/FRESH/ RECIR- CULATION SWITCH
BACKUP LAMP SWITCH (M/T ONLY) PARK/NEUTRAL PSITION (PNP) SWITCH
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE PESSURE MDULATOR VALVE (BPMV)
BRAKE PRESSURE MODULATOR VALVE (BPMV)
BRN WIRE
CRUISE CONTROL MODULE SHIFTLOCK CONTROL MODULE
CRUISE CONTROL RELEASE SWITCH
DAYTIME RUNNING LAMPS (DRL) CONTROL MDULE
DECELE- RATION SENSOR (ABS, AWD ONLY)
DEF FUSE
DEF RELAY
DEF- I/UP FUSE
FAN NO 1 RELAY
FAN NO. 2 RELAY
FLASHER RELAY
FOG FUSE
FOG RELAY
FROM ALT FUSE (DIAGRAM 1 OF 4)
FRONT WASHER MOTOR
FRONT WIPER MOTOR
GAUGE FUSE ECU-IG FUSE
GLASS BREAKAGE SENSOR (W/ THEFT DETERENT) FAN NO 1 RELAY
GRN WIRE
HEATER FUSE
HEATER RELAY
INSTRU- MENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK
MULTI- FUNCTION ALARM MODULE IG 1 RELAY
NOISE FILTER
P/W RELAY
PASSENGER SEAT BELT WARNING LAMP
POWERTRAIN CONTROL MDULE
RDI FAN FUSE
REAR DEFOGGER
REAR DEFOGGER NOISE FILTER
REAR WASHER MOTOR
REAR WIPER DIODE
REAR WIPER RELAY 1
REAR WIPER RELAY 1 VEHICLE SPEED SENSOR (VSS) GENERATOR
RED WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RR WIP FUSE
SP 107 (IN ENG ACCESSORY HARN, NEAR PCM)
SP 109
THEFT DETERENT MODULE (W/ THEFT DETERENT)
TO 115 VOLT POWER OUTLET SWITCH (DIAGRAM 3 OF 4)
TO POWER FUSE (DIAGRAM 3 OF 4)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT, MOUNTED TO INNER FENDER)
WASHER FUSE
WHT WIRE
WIPER FUSE
WIPER/ WASHER SWITCH
Go to component -> Power distribution circuit (2 of 4) -> PASSENGER SEAT BELT WARNING LAMP
Wiring diagram passenger seat belt warning lamp (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
DOOR FUSE
DRIVER SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
GAUGE FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION KEY ALARM SWITCH
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LEFT FRONT COURTESY SWITCH
LEFT INSTRUMENT PANEL JUNCTION BLOCK
MULTI-FUNCTION ALARM MODULE
NCA WIRE
PASSENGER OCCUPENT DETECTION SENSOR
PASSENGER SEAT BELT SWITCH (IN PASSENGER'S SEAT BELT BUCKLE)
PASSENGER SEAT BELT WARNING LAMP
RED WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
SEAT BELT IND
SP 108 (IN ENG ACC HARN, NEAR PCM)
SP 200 (UNDER LEFT SIDE OF DASH)
SP 201 (BEHIND RIGHT BODY HINGE PILLAR TRIM PANEL)
WHT WIRE
YEL WIRE
Go to component -> Warning systems circuit -> PASSENGER SEAT BELT WARNING LAMP
