Wiring diagram open below 178 psi closed above 220 psi (1 of 2)
A/C PRESSURE SW
BLK/RED WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRAKE PRESSOR MODULATOR VALVE (AT RIGHT FRONT SIDE OF ENG COMPT)
CLOSED BETWEEN 28 PSI AND 455 PSI
ECU-IG FUSE
FAN 1 RELAY
FAN 1 RLY CTRL
FAN 2 RELAY
FAN 2 RLY CTRL
FAN MOTOR
FAN RESISTOR
HOT ALL TIMES
HOT IN RUN OR START
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LT GRN WIRE
LT GRN/BLK WIRE
OPEN BELOW 178 PSI CLOSED ABOVE 220 PSI
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
RDI FUSE
REFRIGERANT PRESSURE SWITCH (AT RIGHT SIDE OF ENG COMPT, ON RECEIVER DRIVER)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT, MOUNTED TO INNER FENDER)
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> OPEN BELOW 178 PSI CLOSED ABOVE 220 PSI
Wiring diagram open below 178 psi closed above 220 psi (2 of 2)
BLK/RED WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRAKE PRESSURE MODULATOR VALVE (AT RIGHT FRONT SIDE OF ENG COMPT)
CLOSED BETWEEN 28 PSI AND 455 PSI
ECU-IG FUSE
FAN 1 RELAY
FAN 2 RELAY
FAN MOTOR
FAN RESISTOR
HOT ALL TIMES
HOT IN RUN OR START
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LT GRN WIRE
LT GRN/BLK WIRE
OPEN BELOW 178 PSI CLOSED ABOVE 220 PSI
RDI FUSE
REFRIGERANT PRESSURE SWITCH (AT RIGHT SIDE OF ENG COMPT, ON RECEIVER DRIVER)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT, MOUNTED TO INNER FENDER)
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> OPEN BELOW 178 PSI CLOSED ABOVE 220 PSI
