Pontiac Vibe I (2002-2004) line pressure control solenoid Wiring diagrams
This page contains all the electrical diagrams for the component. line pressure control solenoid, in which he is found in the car Pontiac Vibe I (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram line pressure control solenoid (1 of 2)
1 3 18 19 20 IGNITION BATTERY SERIAL DATA DATA LINK DIAGNOSTIC
5 7 13 14 15 28 GROUND GROUND TCC SOL SHIFT SOL 2 SHIFT SOL 1 GROUND
6 7 16 17 18 19 21 28 GROUND GROUND LINE PC SOL LO LINE PC SOL HI
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
ECT SENS IN TP SENS IN SENSOR GND
EFI RELAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN)
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN) STOP FUSE
LEFT FRONT STRUT TOWER)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LINE PRESSURE CONTROL SOLENOID
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
O/D IND LAMP
OVERDRIVE SWITCH
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
PPL/WHT WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK
RUN WIRE
SHIFT SOLENOID 1
SHIFT SOLENOID 2 TCC SOLENOID
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
THROTTLE POSITION SENSOR (REAR OF THROTTLE BODY)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) EFI FUSE
VS OUT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> A/t circuit, fwd -> LINE PRESSURE CONTROL SOLENOID
Wiring diagram line pressure control solenoid (2 of 2)
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAID
BRAKE SOLENOID
BRN WIRE
CRUISE CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
ECT IN
EVAP CANISTER PURGE SOLENOID VALVE (NEXT TO AIR CLEANER)
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN)
INTAKE AIR TEMP
KNOCK SENSOR (BELOW INTAKE MANIFOLD)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LINE PRESSURE CONTROL SOLENOID
LT GRN WIRE
LT GRN/BLK WIRE
MALFUNCTION INDICATOR LAMP
MASS AIR FLOW SENSOR (TOP OF AIR CLEANER ASSY)
O/D INDICATOR LAMP
PARK/ NEUTRAL POSITION SWITCH
PNK 4 5 6 WIRE
PNK WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK
SHIFT SOLENOID 2
STOP FUSE
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
TACH IN
TCC SOLENOID SHIFT SOLENOID 1
TRANSMISSION FLUID TEMPERATURE SENSOR
VS OUT
WHT WIRE
WHT/BLU WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8, awd (2 of 3) -> LINE PRESSURE CONTROL SOLENOID
