Pontiac Vibe I (2002-2004) ip cluster ip lmp dimr feed ip cluster ip illum supply ctsy lmps cntrl Wiring diagram
This page shows the only wiring diagram for the component.ip cluster ip lmp dimr feed ip cluster ip illum supply ctsy lmps cntrl, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ip cluster ip lmp dimr feed ip cluster ip illum supply ctsy lmps cntrl (1 of 1)
115 VOLT POWER OUTLET SWITCH
12 13 TAIL RLY CNTRL PRK LMPS SIG
7 6 ILLUMINATION ILLUMINATION
8 7 6 5 4 3 2 1 F, R DOME CNTRL GROUND
A/C FRESH RECIRCULATION SWITCH
BLK WIRE
BLOWER MOTOR SWITCH
CIGAR LIGHTER
COURTESY LIGHTS
DEFOGGER SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HAZARD SWITCH
HEAD
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL LAMP DIMMER
IP CLUSTER IP LMP DIMR FEED IP CLUSTER IP ILLUM SUPPLY CTSY LMPS CNTRL
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LIGHT SWITCH
OVERDRIVE SWITCH
PARK OFF
RADIO
RED/BLK WIRE
RED/WHT WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK
TAIL FUSE
TAIL RELAY
TURN SIGNAL/ HEADLAMP SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Instrument illumination circuit -> IP CLUSTER IP LMP DIMR FEED IP CLUSTER IP ILLUM SUPPLY CTSY LMPS CNTRL
