Pontiac Vibe I (2002-2004) high mist low off off int int Wiring diagram
This page shows the only wiring diagram for the component.high mist low off off int int, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high mist low off off int int (1 of 1)
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
FRONT WASHER MOTOR
FRONT WIPER MOTOR (ON RIGHT SIDE OF FIREWALL)
GAUGE FUSE
HIGH LOW
HIGH MIST LOW OFF OFF INT INT
HOT IN RUN OR START
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LOW OFF INT
LOW WASHER FLUID LEVEL IND
MIST
REAR WASHER MOTOR
RED/WHT WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
SP 109
SP 200 (UNDER LEFT SIDE OF DASH)
WASH SWITCH ON OFF
WASHER FUSE
WHT/BLK WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WIPER FUSE
WIPER/ WASHER SWITCH
WIPER/WASHER LOGIG CIRCUIT
