Pontiac Vibe I (2002-2004) ground start feed crank sig starting system Wiring diagram
This page shows the only wiring diagram for the component.ground start feed crank sig starting system, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground start feed crank sig starting system (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22-31 (NOT USED) IGNITION
6 7 8 9 PNK WIRE
BLK WIRE
BLK/ WHT WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAID
BRN WIRE
CIRCUIT OPENING RELAY
COOLING FANS SYSTEM
CRUISE CONTROL SYSTEM
CRUISE IDLE
DEFOGGER SYSTEM
EFI RELAY
EVAP PRESSURE SWITCHING SOLENOID (BEHIND FUEL TANK)
FUEL PUMP
FUEL SENDER ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GROUND (LEFT SIDE OF CYLINDER HEAD)
GROUND PSP SW IN
GROUND START FEED CRANK SIG STARTING SYSTEM
HEATED OXYGEN SENSOR 1 (IN EXHAUST MANIFOLD)
HEATED OXYGEN SENSOR 2 (IN EXHAUST PIPE, AFTER CONVERTER)
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN)
LEFT FRONT STRUT TOWER)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LOCK
MAF SENS HI
MAF SENS LO RAOP SW IN
PNK WIRE
PNK/BLK WIRE
POWER STEERING PRESSURE SWITCH (TOP OF POWER STEERING PUMP)
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
ROCKER ARM OIL PRESSURE SWITCH (RIGHT SIDE OF ENGINE)
RUN WIRE
SERIAL DATA DATA LINK DIAGNOSTIC FTP SENS IN
SUPPLEMENTAL RESTRAINTS SYSTEM
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) EFI FUSE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l vin l (1 of 3) -> GROUND START FEED CRANK SIG STARTING SYSTEM
