Pontiac Vibe I (2002-2004) front cigar lighter illumination Wiring diagram
This page shows the only wiring diagram for the component.front cigar lighter illumination, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front cigar lighter illumination (1 of 1)
A/C FRESH RECIRCULATION SWITCH
A/C/ FRESH/ RECIRCULATION SWITCH ILLUMINATION
BLK WIRE
BLOWER MOTOR SWITCH ILLUMINATION
DECELERATION SENSOR (ABS, AWD)
DEFOGGER SWITCH ILLUMINATION
DRIVER SEAT BELT SWITCH PASSENGER SEAT BELT SWITCH
FRONT CIGAR LIGHTER ILLUMINATION
GLASS BREAKAGE SENSOR
HAZARD SWITCH ILLUMINATION
HAZARD SWITCH OVERDRIVE SWITCH
INV RELAY
OVERDRIVE SWITCH ILLUMINATION
P-POINT RELAY
POWER OUTLET SWITCH
POWER OUTLET SWITCH ILLUMINATION
RADIO ILLUMINATION
RIGHT INSTRUMENT PANEL JUNCTION BLOCK
SECURITY INDICATOR
SHIFT LOCK CONTROL MODULE
THEFT DETERRENT MODULE (IF EQUIPPED)
WHT WIRE
Go to component -> Ground distribution circuit (4 of 4) -> FRONT CIGAR LIGHTER ILLUMINATION
