Pontiac Vibe I (2002-2004) ect sens in tp sens in sensor gnd Wiring diagram
This page shows the only wiring diagram for the component.ect sens in tp sens in sensor gnd, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ect sens in tp sens in sensor gnd (1 of 1)
1 3 18 19 20 IGNITION BATTERY SERIAL DATA DATA LINK DIAGNOSTIC
5 7 13 14 15 28 GROUND GROUND TCC SOL SHIFT SOL 2 SHIFT SOL 1 GROUND
6 7 16 17 18 19 21 28 GROUND GROUND LINE PC SOL LO LINE PC SOL HI
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
ECT SENS IN TP SENS IN SENSOR GND
EFI RELAY
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN)
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN) STOP FUSE
LEFT FRONT STRUT TOWER)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LINE PRESSURE CONTROL SOLENOID
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
O/D IND LAMP
OVERDRIVE SWITCH
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
PPL/WHT WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK
RUN WIRE
SHIFT SOLENOID 1
SHIFT SOLENOID 2 TCC SOLENOID
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
THROTTLE POSITION SENSOR (REAR OF THROTTLE BODY)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) EFI FUSE
VS OUT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> A/t circuit, fwd -> ECT SENS IN TP SENS IN SENSOR GND
