Pontiac Vibe I (2002-2004) co relay mil ctrl idle-up tail idle-up defog sir fuel cutoff Wiring diagrams
This page contains all the electrical diagrams for the component. co relay mil ctrl idle-up tail idle-up defog sir fuel cutoff, in which he is found in the car Pontiac Vibe I (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram co relay mil ctrl idle-up tail idle-up defog sir fuel cutoff (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22-31 (NOT USED) IGNITION
BATTERY EVAP PRESS SOL TACH OUT FAN 1 RELAY FAN 2 RELAY
BLK WIRE
BLK/ WHT WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAID
BRN WIRE
CIRCUIT OPENING RELAY
CO RELAY MIL CTRL IDLE-UP TAIL IDLE-UP DEFOG SIR FUEL CUTOFF
COOLING FANS SYSTEM
CRUISE IDLE
DEFOGGER SYSTEM
EFI RELAY
EVAP PRESSURE SWITCHING SOLENOID (BEHIND FUEL TANK)
FUEL PUMP
FUEL SENDER ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GROUND (LEFT SIDE OF CYLINDER HEAD)
GROUND START FEED STARTING SYSTEM
HEATED OXYGEN SENSOR 1 (IN EXHAUST MANIFOLD)
HEATED OXYGEN SENSOR 2 (IN EXHAUST PIPE, AFTER CONVERTER)
HOT AT ALL TIMES
IGNITION SWITCH
INPUT SHAFT SPEED SENSOR
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN)
ISS SENS HI GROUND PSP SW IN
ISS SENS LO
LEFT FRONT STRUT TOWER)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LOCK
MAF SENS HI
MAF SENS LO
PNK WIRE
PNK/BLK WIRE
POWER STEERING PRESSURE SWITCH (TOP OF PWR STEERING PUMP)
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RUN WIRE
SERIAL DATA DATA LINK DIAGNOSTIC FTP SENS IN
SS ST SOL TCC SOL SHIFT SOL 2 SHIFT SOL 1
SUPPLEMENTAL RESTRAINTS SYSTEM
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) EFI FUSE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8, awd (1 of 3) -> CO RELAY MIL CTRL IDLE-UP TAIL IDLE-UP DEFOG SIR FUEL CUTOFF
Wiring diagram co relay mil ctrl idle-up tail idle-up defog sir fuel cutoff (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22-31 (NOT USED) IGNITION
BATTERY EVAP PRESS SOL TACH OUT FAN 1 RELAY FAN 2 RELAY
BLK WIRE
BLK/ WHT WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAID
BRN WIRE
CIRCUIT OPENING RELAY
CO RELAY MIL CTRL IDLE-UP TAIL IDLE-UP DEFOG SIR FUEL CUTOFF
COOLING FANS SYSTEM
CRUISE IDLE
DEFOGGER SYSTEM
EFI RELAY
EVAP PRESSURE SWITCHING SOLENOID (BEHIND FUEL TANK)
FUEL PUMP
FUEL SENDER ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GROUND (LEFT SIDE OF CYLINDER HEAD)
GROUND PSP SW IN
GROUND START FEED CRANK SIG (A/T) (M/T) STARTING SYSTEM
HEATED OXYGEN SENSOR 1 (IN EXHAUST MANIFOLD)
HEATED OXYGEN SENSOR 2 (IN EXHAUST PIPE, AFTER CONVERTER)
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN)
LEFT FRONT STRUT TOWER)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LOCK
MAF SENS HI
MAF SENS LO
PNK WIRE
PNK/BLK WIRE
POWER STEERING PRESSURE SWITCH (TOP OF POWER STEERING PUMP)
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RUN WIRE
SERIAL DATA DATA LINK DIAGNOSTIC FTP SENS IN
SUPPLEMENTAL RESTRAINTS SYSTEM
TCC SOL SHIFT SOL 2 SHIFT SOL 1
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) EFI FUSE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8, fwd (1 of 3) -> CO RELAY MIL CTRL IDLE-UP TAIL IDLE-UP DEFOG SIR FUEL CUTOFF
