Car Wiring Diagrams for Charging circuit for Pontiac Torrent I (2005-2009)

AIR BAG DISPLAY FUSE BATTERY BATTERY CURRENT SENSOR (UNDER UNDERHOOD FUSE BLOCK) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) BRN WIRE CHARGE IND CLASS 2 (PCM) COMPUTER DATA LINES SYSTEM CURRENT SENSOR CURRENT SENSOR SIG DK GRN WIRE ENGINE CONTROL MODULE (ECM) (MOUNTED ON TOP OF BATTERY COVER) FUSIBLE LINK (8 GA- GENERATOR GENERATOR FIELD DUTY CYCLE SIGNAL GENERATOR TURN ON SIGNAL GROUND GRY WIRE HIGH SPEED GMLAN SERIAL DATA BUS + HOT AT ALL TIMES HOT W/ IGN 1 RELAY ENERGIZED IGN INSTRUMENT PANEL CLUSTER (IPC) IP/FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LOGIC LOW REF LOW SPEED GMLAN SERIAL DATA BATTERY POSITIVE VOLTAGE LOW SPPED GMLAN SERIAL DATA LT BLU WIRE ORG/ WIRE PNK CURRENT SENSOR SUPPLY VOLTAGE WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/WHT WIRE RVC FUSE STARTER TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE
