Ignition lock solenoid circuit for Pontiac Torrent I (2005-2009)
Ignition lock solenoid circuit
BAT POS VOT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
GRY WIRE
HOT AT ALL TIMES
IGN LK CYD SOL CNTRL
IGNITION LOCK SOLENOID (RIGHT SIDE OF STEERING COLUMN, BEHIND IGNITION SWITCH)
PPL/WHT WIRE
PRNDL SWITCH
RED/WHT WIRE
RVC FUSE (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK
