Electrochromic mirror circuit for Pontiac Torrent I (2005-2009)
Electrochromic mirror circuit
11 6 3 2 KEY SIGNAL KEY SPLY VOLT GREEN LED SIG
AMBIENT LIGHT SENSOR
BACKUP SPLY
BLK WIRE
BRN/WHT WIRE
DK GRN/WHT WIRE
GROUND BACKUP LMP SPLY VOLT
HOT W/ RAP PCB RELAY ENERGIZED
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
IGN
INSIDE REARVIEW MIRROR
KEY SIG KEY SPLY VOLT ACC VOLT GREEN LED SIG
LT GRN WIRE
LT GRN/BLK WIRE
MAGNETIC FIELD SENSOR LOGIC
MESS REQ IGN LOW REF
MIRROR DISPLAY
MIRROR SIG AUTOMATIC DAY/NIGHT MIRROR ELEMENT
RED LED SIG WIRE
S/ROOF FUSE
SENS SIG
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (ATTACHED TO BRAKE PEDAL BRACKET)
YEL WIRE
YEL/BLK WIRE
