Computer data lines circuit for Pontiac Torrent I (2005-2009)

Computer data lines circuit (1 of 2)

Torrent Pontiac I (2005-2009): Computer data lines circuit (1 of 2)

Get access

ALL WHEEL DRIVE MODULE BLK WIRE BLK/WHT WIRE DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH) DIGITAL RADIO RECEIVER (ATTACHED TO LEFT WHEELHOUSE, UNDER LEFT TRIM PANEL) DK GRN WIRE HEATED SEAT CONTROL MODULE (UNDER RIGHT FRONT SEAT) HOT AT ALL TIMES HVAC CONTROL MODULE (AT CENTER OF DASH) HVAC/RFA FUSE 15 I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) INFLATABLE RESTRAINT PASSENGER PRESENSE (PPS) MODULE (UNDER PASSENGER SEAT) INSTRUMENT PANEL CLUSTER (IPC) LOW SERIAL DATA LT BLU WIRE POWER DISTRIBUTION SYSTEM POWER STEERING CONTROL MODULE (PSCM) RADIO RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (ON RIGHT "C" PILLAR) ROLLOVER SENSOR (UNDER REAR CENTER OF CONSOLE, BEHIND SDM) SERIAL DATA COMMUNICATION ENABLE SPLICE PACK TAN WIRE TAN/BLK WIRE THEFT DETERRENT MODULE (TDM) (NEAR TOP OF STEERING COLUMN) W/ DIGITAL AUDIO SYSTEM W/ ONSTAR

Computer data lines circuit (2 of 2)

Torrent Pontiac I (2005-2009): Computer data lines circuit (2 of 2)

Get access

6 SPEED A/T BRN/WHT WIRE CAN BUS HI CAN BUS HI SERIAL DATA CAN BUS LOW CAN BUS LOW SERIAL DATA DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (BELOW BRAKE MASTER CYLINDER) ELECTRONIC POWER STEERING MODULE (EPS) (LOWER LEFT SIDE OF STEERING COLUMN) ENGINE CONTROL MODULE (ECM) (MOUNTED ON TOP OF BATTERY COVER) EXCEPT 6 SPEED A/T HIGH DATA BUS + HIGH SERIAL DATA BUS + LOW SERIAL DATA LT BLU WIRE LT GRN/BLK WIRE REAR DIFFERENTIAL CLUTCH CONTROL MODULE (ON TOP REAR OF REAR DIFFERENTIAL) SERIAL DATA SERIAL DATA COMMUNICATION ENABLE TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TERMINATOR RESISTOR (BEHIND CENTER OF FUEL TRANSMISSION CONTROL MODULE (TCM) (AT LEFT REAR CORNER OF ENGINE COMPARTMENT) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (ATTACHED TO BRAKE PEDAL BRACKET) W/ ONSTAR W/O ONSTAR W/ ONSTAR WHT/BLK WIRE YAW RATE LATERAL ACCELEROMETER SENSOR (UNDER PASSENGER SEAT)
