Power door locks circuit, with keyless entry for Pontiac Sunfire I (1995-2005)
Power door locks circuit, with keyless entry
BATTERY
BLK WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
DOOR LOCK RELAY
DOOR LOCK/ UNLOCK RELAY (BEHIND RIGHT SIDE OF DASH)
DOOR UNLOCK RELAY
DRIVER DOOR LOCK MOTOR
DRIVER DOOR LOCK SWITCH
FRONT PASSENGER DOOR LOCK MOTOR
FRONT PASSENGER DOOR LOCK SWITCH
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
LEFT REAR DOOR LOCK MOTOR (4 DOOR)
LF DOOR LOCK/ UNLOCK CTRL
LOCK
LOCK CTRL
LT BLU WIRE
ORG/ WIRE
PWR ACCY FUSE
RFA BATT FUSE
RIGHT REAR DOOR LOCK MOTOR (4 DOOR)
TAN WIRE
UNLOCK
UNLOCK CTRL
WHT WIRE
