Ground distribution circuit for Pontiac Sunfire I (1995-2005)

Ground distribution circuit (1 of 3)

Get access

BATTERY BLK WIRE BODY CONTROL MODULE BRAKE FLUID LEVEL SWITCH COOLANT LEVEL SWITCH CRUISE CONTROL MODULE DATA LINK CONNECTOR (DLC) DAYTIME RUNNING LAMP (DRL) RESISTOR EARLY PRODUCTION FUEL PUMP RELAY GROUND SPLICE PACK 102 (UNDER BATTERY TRAY) HORN IGNITION CONTROL MODULE INSTRU- MENT PANEL CLUSTER INSTRUMENT CLUSTER CONNECTORS) LATE PRODUCTION LEFT FRONT FOG LAMP LEFT FRONT PARK/ TURN LAMP LEFT FRONT PARK/ TURN LAMP RIGHT FRONT PARK/ TURN LAMP PARK/ NEUTRAL POSITION SWITCH PONTIAC CHEVROLET POWERTRAIN CONTROL MODULE RIGHT FRONT FOG LAMP RIGHT FRONT PARK/ TURN LAMP TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD FUSE BLOCK WHT WIRE WINDSHIELD WASHER FLUID PUMP WINDSHIELD WASHER FLUID PUMP LEFT FRONT FOG LAMP WINDSHIELD WIPER MOTOR ASSEMBLY

Get access

ACCESSORY POWER OUTLET ALL OTHERS AUDIO AMPLIFIER BLK WIRE BODY CONTROL MODULE CHEVROLET ENHANCED AUDIO CIGAR LIGHTER DATA LINK CONNECTOR DIGITAL RADIO RECEIVER FOG LAMP SWITCH HVAC CONTROL ASSEMBLY I/P DIMMER SWITCH IGNITION SWITCH INSTRUMENT PANEL CLUSTER LEFT READING/ COURTESY LAMP SWITCH PONTIAC ENHANCED AUDIO PONTIAC ONLY RADIO REAR COMPARTMENT LID RELEASE SWITCH REARVIEW MIRROR READING LAMPS RIGHT READING/ COURTESY LAMP SWITCH SHIFT INDICATOR LAMP SUNROOF CONTROL MODULE TRACTION CONTROL SWITCH TURN SIGNAL/ HAZARD FLASHER MODULE W/ POWER SUNROOF W/O POWER SUNROOF WHT WIRE

Get access

A/C COMP- RESSOR CLUTCH A/C COMP- RESSOR CLUTCH DIODE BLK WIRE BLK/WHT WIRE CENTER HIGH MOUNTED STOP LAMP ASSEMBLY (CHMSL) COOLING FAN DOOR JAMB SWITCH- DRIVER DOOR LOCK SWITCH- FRONT PASSENGER ELECTRONIC BRAKE CONTROL MODULE FRONT PASSENGER DOOR JAMB SWITCH DOOR LOCK RELAY FUEL PUMP, SENDER ASSEMBLY FUSE BLOCK- UNDERHOOD HEATER BLOWER RELAY CRANK RELAY LEFT BACK-UP LAMP LEFT CENTER HIGH MOUNTED STOP LAMP ASSEMBLY LEFT REAR APPLIQUE LAMP RIGHT REAR APPLIQUE LAMP LEFT REAR DOOR JAMB SWITCH RIGHT REAR DOOR JAMB SWITCH LEFT REAR MARKER LAMP LICENSE LAMP MASTER WINDOW SWITCH NCA WIRE ON FRAME RAIL) PONTIAC RADIO REAR COMPARTMENT LID RELEASE ACTUATOR SEAT BELT SWITCH REAR WINDOW DEFOGGER GRID RIGHT BACK-UP LAMP RIGHT CENTER HIGH MOUNTED STOP LAMP ASSEMBLY RIGHT REAR MARKER LAMP SEDAN SEDAN, COUPE TAIL/ STOP, TURN SIGNAL LAMP- RIGHT TAIL/ STOP/ TURN LAMP LEFT W/ KEYLESS REMOTE W/ MANUAL A/C W/ SPOILER W/O KEYLESS REMOTE W/O SPOILER
