Pontiac Sunfire I (1995-2005) volts indicator wiring diagram
This page shows the only wiring diagram for the component.volts indicator, which is found in the car Pontiac Sunfire I (1995-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
volts indicator wiring diagram (1 of 1)
1440 39 1807 1807 PNK PPL PPL WIRE
BATTERY
BCM/CLU FUSE
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND LOWER LEFT SIDE OF DASH)
CLSTR FUSE
COMPUTER DATA LINES SYSTEM
FUSIBLE LINK G
GENERATOR
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN, START
I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
INSTRUMENT PANEL CLUSTER (IPC)
ORG/ WIRE
PNK PNK WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM) (ON RIGHT FRONT OF ENGINE COMPARTMENT)
PPL
PPL PPL 1807 1807 SERIAL DATA CLASS 2 SERIAL DATA CLASS 2
RED WIRE
STARTER SOLENOID
SWITCHED VOLTAGE
VOLTS INDICATOR
Go to component -> Charging circuit -> VOLTS INDICATOR
