Pontiac Sunfire I (1995-2005) sun roof control module sun roof close input wiring diagram
This page shows the only wiring diagram for the component.sun roof control module sun roof close input, which is found in the car Pontiac Sunfire I (1995-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sun roof control module sun roof close input wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE
DK BLU WIRE
DK GRN WIRE
GND MTR MTR
HOT IN RUN
I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
IGNITION
OPEN/ VENT
ORG/ WIRE
PNK WIRE
PWR WINDOW CIRCUIT BREAKER
RED WIRE
SOFT STOP LIMIT SWITCH
SUN ROOF ASSEMBLY (IN HEADLINER)
SUN ROOF CONTROL MODULE SUN ROOF CLOSE INPUT
SUN ROOF MOTOR ASSEMBLY
SUN ROOF OPEN INPUT
SUN ROOF POSITION INPUT
SUN ROOF SWITCH
SUN-ROOF MOTOR
VENT LIMIT SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> SUN ROOF CONTROL MODULE SUN ROOF CLOSE INPUT
