Pontiac Sunfire I (1995-2005) pass dr sig Wiring diagram
This page shows the only wiring diagram for the component.pass dr sig, which is found in the car Pontiac Sunfire I (1995-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass dr sig (1 of 1)
B+ VOLTAGE
BASE
BLK WIRE
BODY CONTROL MODULE (BEHIND LOWER LEFT SIDE OF DASH)
DIODE
DOME LAMP
DRIVER DOOR JAMB SWITCH
DRIVR DR SIG
FRONT PASSENGER DOOR JAMB SWITCH
HOT AT ALL TIMES
I/P DIMMER SWITCH
I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
INADVERTENT PWR CTRL (SW BATT VOLTAGE)
INTERIOR LMP CTRL
LEFT READING LAMP
LEFT READING LAMP SWITCH
LEFT REAR DOOR JAMB SWITCH
LT BLU WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASS DR SIG
RDO/ INTLP FUSE
REAR COMPARTMENT LAMP
REAR COMPARTMENT LAMP INPUT
REAR COMPARTMENT LAMP SWITCH
REAR VIEW MIRROR READING LAMPS (W/SUNROOF)
RIGHT READING LAMP
RIGHT READING LAMP SWITCH
RIGHT REAR DOOR JAMB SWITCH
SEDAN
W/ POWER DOOR LOCKS
W/O POWER DOOR LOCKS
WHT WIRE
Go to component -> Courtesy lamps circuit -> PASS DR SIG
