Pontiac Sunfire I (1995-2005) drvr dr jamb sig Wiring diagram
This page shows the only wiring diagram for the component.drvr dr jamb sig, which is found in the car Pontiac Sunfire I (1995-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drvr dr jamb sig (1 of 1)
1807 1807 PPL PPL SERIAL DATA SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRN WIRE
DRIVER DOOR JAMB SWITCH
DRVR DR JAMB SIG
GRN WIRE
IGN KEY IN SW
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MULTI- FUNCTION SWITCH
NCA WIRE
PARK BRAKE SWITCH (IN CENTER CONSOLE)
PARK BRK SW SIG
PARK LAMP VOLT
POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE COMPARTMENT)
PPL
PPL SERIAL DATA
RADIO CLASS 2 SERIAL DATA
SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
SWITCH INPUT SERIAL DATA PPL
TURN SIGNAL
WHT WIRE
Go to component -> Warning systems circuit -> DRVR DR JAMB SIG
