Pontiac Solstice I (2005-2009) outside air temperature sensor breakout) Wiring diagram
This page shows the only wiring diagram for the component.outside air temperature sensor breakout), which is found in the car Pontiac Solstice I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside air temperature sensor breakout) (1 of 1)
2.0L
2.0L 2.0L
2.4L
ACCESSORY STEERING
BATTERY
BLK WIRE
BRAKE BOOSTER PUMP MOTOR
BRAKE FLUID LEVEL SWITCH
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM)
ENGINE COOLANT LEVEL SWITCH
ENGINE COOLING FAN
FOG LAMP RELAY 54
HORN
HORN SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3 IGNITION COIL 4
INFLATABLE RESTRAINT PASSENGER PRESENCE SYSTEM (PPS) MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL COIL
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT FOG LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/TURN LAMP
LEFT HEADLAMP
LEFT STEERING WHEEL CONTROL SWITCH
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
NCA WIRE
OUTSIDE AIR TEMPERATURE SENSOR BREAKOUT)
REAR DEFOG RELAY 14 FUEL PUMP RELAY 19
RIGHT FRONT FOG LAMP
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT HEADLAMP
RIGHT STEERING WHEEL CONTROL SWITCH
RUN/CRNK RELAY 51
WHEEL CONTROL
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR ASSEMBLY
WPR RELAY 52
WPR RELAY 70
Go to component -> Ground distribution circuit (1 of 2) -> OUTSIDE AIR TEMPERATURE SENSOR BREAKOUT)
