Pontiac Solstice I (2005-2009) (at left front corner of Wiring diagram
This page shows the only wiring diagram for the component.(at left front corner of, which is found in the car Pontiac Solstice I (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (at left front corner of (1 of 1)
59 18 31 9 67 66 5 LOW REFERENCE
APPROXIMATELY 40.5 CM FROM HORN BREAKOUT)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (RIGHT OF HVAC MODULE)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL LEVER)
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
CORNER OF THE ENGINE COMPT)
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE COMPT, MOUNTED ON FRAME RAIL)
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HAZARD SWITCH
HEAD PARK AUTO
HOT AT ALL TIMES
INTERIOR LIGHTS
LEFT FRONT PARK/ TURN LAMP
LEFT MARKER LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP
LICENSE LAMP
LOGIC
LR SPLY VOLTAGE RR SPLY VOLT
LT BLU WIRE
OFF
PRK LAMPS FUSE 69
PRK LAMPS RELAY 68
RIGHT FRONT PARK/ TURN LAMP
RIGHT MARKER LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP
SYSTEM (IN I/P BODY HARNESS, APPROXIMATELY 33 CM FROM REAR COMPT LAMP)
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (IN THE RIGHT REAR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit -> (AT LEFT FRONT CORNER OF
