Pontiac Solstice I (2005-2009) 42 55 66 67 serial data bus + serial data bus - vss high sig vss low sig Wiring diagram

24 48 88 89 39 90 TAC MTR CTRL 1 TAC MTR CTRL 2 LOW REF TP SEN SIG 2 42 55 66 67 SERIAL DATA BUS + SERIAL DATA BUS - VSS HIGH SIG VSS LOW SIG 47 48 25 34 49 15 PPL LOW REF ACCELERATOR PEDAL POSITION (APP) SENSOR (TOP OF ACCELERATOR PEDAL BRACKET) APP SNSR 1 SIG APP SNSR 2 SIG LOE REF BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (RIGHT OF HVAC MODULE) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL LEVER) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CPP SW SIG CRUISE CONTROL SW SIG DK BLU WIRE DK GRN WIRE EMISSIONS FUSE EPS/STR WHL CNTRL FUSE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LEFT STEERING WHEEL CONTROL SWITCH LOGIC LT BLU WIRE ON OFF PNK WIRE PPL R/A REF S/C SERIAL DATA BUS - BPP SENS SIG LOW REF SERIAL DATA BUS- TAN WIRE TAN/BLK WIRE TP SENS 2 SIG UNDERHOOD FUSE BLOCK (IN RIGHT REAR CORNER OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (M/T) (ON SIDE OF MANUAL TRANSMISSION) WHT WIRE WHT/BLK WIRE YEL WIRE
