Courtesy lamps circuit for Pontiac Montana I (1997-2005)
Courtesy lamps circuit
B+ OUTPUT CTSY LPS CTRL B+ INPUT
BLK WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH)
CARGO LAMP
DK BLU WIRE
DOME
DOME LAMP
DRIVER DR AJAR INT LPS ON PASS DR AJAR SLIDING DR AJAR
GRY WIRE
GRY/BLK WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES FUSE BLOCK CTSY LAMP FUSE
I/P COMPARTMENT LAMP (2002)
INTERIOR LAMP, MULTI- FUNCTION SWITCH
INTERIOR LAMPS OVERRIDE SWITCH
LEFT FOOOTWELL COURTESY LAMP (2002)
LEFT FRONT DOOR AJAR INDICATOR SWITCH
LEFT FRONT ROOF RAIL READING LAMP
LEFT REAR ROOF RAIL READING LAMP
LEFT SLIDING DOOR JAMB SWITCH
LEFT VANITY MIRROR LAMP
LIFTGATE DOOR AJAR INDICATOR SWITCH
NCA WIRE
OFF
ORG/ WIRE
PPL
PPL (ROOF HARN, RIGHT OF OVERHEAD CONSOLE)
RIGHT FOOTWELL COURTESY LAMP (2002)
RIGHT FRONT DOOR AJAR INDICATOR SWITCH
RIGHT SLIDING DOOR JAMB SWITCH
RIGHT VANITY MIRROR LAMP
TAN WIRE
WHT WIRE
WINDSHIELD HEADER COURTESY/ READING LAMPS
