Exterior lamps circuit for Pontiac Montana I (1997-2005)

Exterior lamps circuit (1 of 2)

Get access

BATTERY (B+) LFT TURN OUT LFT TURN IN EXT LAMPS CTRL BLK WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH) BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE HAZARD FUSE HEAD HEADLAMP SWITCH HEADLIGHTS (FOGLAMPS) HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING) INSTRUMENT PANEL CLUSTER LEFT TURN IN RIGHT TURN IN LT BLU WIRE LT BLU/WHT WIRE OFF ORG/ WIRE PARK PARK LP FUSE PNK PPL WIRE PNK WIRE PPL RKE LAMP SIG RKE LAMP SIG RT TURN IN LFT TURN IN RT TURN OUT RT TURN IN T/SIG FUSE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, FRONT OF RIGHT WHEELHOUSE ABOVE BATTERY) YEL WIRE

Get access

BLK WIRE BRN WIRE CENTER HIGH MOUNTED STOP LAMP (CHMSL) DK BLU WIRE DK GRN WIRE ELC FUSE HOT AT ALL TIMES I/P FUSE BLOCK (RIGHT SIDE OF DASH, IN RIGHT FRONT DOOR OPENING) LEFT FRONT MARKER LAMP LEFT FRONT PARK/TURN SIGNAL LAMP LEFT REAR TAIL LAMP LEFT REAR TAIL/STOP LAMP LEFT REAR TURN SIGNAL LAMP LEFT SIDE MIRROR TURN INDICATOR LIGHT LEFT TAILLAMP LICENSE LAMPS LT BLU WIRE NCA WIRE ORG/ WIRE RED WIRE RIGHT FRONT MARKER LAMP RIGHT FRONT PARK/TURN SIGNAL LAMP RIGHT REAR TAIL LAMP RIGHT REAR TAIL/STOP LAMP RIGHT REAR TURN SIGNAL LAMP RIGHT SIDE MIRROR TURN INDICATOR LIGHT RIGHT TAILLAMP STOP LAMP FUSE STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT) TRAILER WIRING HARNESS (CUT AS BLUNT ENDS) UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE
