Shift interlock circuit for Pontiac GTO IV (2004-2006)
Shift interlock circuit
A/T SHIFT LOCK CONTROL SOLENOID
BLK WIRE
BLK/GRN WIRE
CRUISE CONTROL, POWER MIRRORS FUSE
DK GRN/WHT WIRE
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION SWITCH
INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH)
LOCK OFF
LT BLU WIRE
PNK WIRE
RED WIRE
RUN WIRE
SHIFT LOCK CONTROL RELAY
SHIFT LOCK CONTROL SOLENOID ASSEMBLY
SPLICE PACK
STOP LAMP SWITCH (ON TOP OF BRAKE PEDAL SUPPORT)
SWITCH OPEN WHEN PARK IS SELECTED
TAN WIRE
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
