Exterior lamps circuit for Pontiac GTO IV (2004-2006)

AUTO BACK-UP LAMPS CIRCUIT BACKUP LAMPS CIRCUIT BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH) BRN WIRE BRN/WHT WIRE FLASHER RELAY GRY WIRE HAZARD SWITCH HDLMPS OFF HDLMPS ON HDLP RET HEAD HEADLAMP SWITCH HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN RUN OR ACC HZRD SW SIG INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH) LEFT FRONT MARKER LAMP LEFT FRONT PARK/TURN SIGNAL LAMP LEFT REAR TURN SIGNAL LAMP LT BLU WIRE OFF ORG/ WIRE PARK PARK LAMP TURN LAMP PARK LAMPS FUSE PARK LAMPS RELAY PPL PRK LP RET RED WIRE RIGHT FRONT MARKER LAMP PARK LAMP RIGHT FRONT PARK/TURN SIGNAL LAMP RIGHT REAR TURN SIGNAL LAMP SENSE TURN LAMP TURN SIGNALS, BACKUP LAMPS FUSE WHT WIRE WHT/RED WIRE YEL WIRE

1 2 3 4 5 6 7 LT SIG RV GND RT SIG TRLR BRK STP PK LP 13 11 LEFT TURN IND RIGHT TURN IND 6 5 1 2 3 4 PK LP STP 6 5 3 1 2 4 PK LP STP RT SIG BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH) BRN WIRE BRN/WHT WIRE CENTER HIGH MOUNTED STOP LAMP CENTER HIGH MOUNTED STOP LAMP (SPOILER) CRUISE CONTROL SYSTEM DK BLU WIRE GRN WIRE GRN/WHT WIRE HAZARD LAMPS FUSE HAZARD/ THEFT INDICATOR RELAY HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH) LEFT TAIL/ STOP LAMP LICENSE LAMPS LT BLU WIRE NCA WIRE ORG/ WIRE PARK LAMP PPL PWR RED WIRE RED/WHT WIRE RIGHT TAIL/ STOP LAMP RT SIG RV STOP LAMP STOP LAMP SWITCH (ON TOP OF BRAKE PEDAL SUPPORT) STOP LAMPS FUSE TRAILER HARNESS CONNECTOR TRAILER HARNESS CONNECTOR A TRAILER HARNESS CONNECTOR B TRAILER SWITCH CLOSED WHEN DUST COVER IS CLOSED TURN SIGNAL/ MULTIFUNCTION SWITCH WHT WIRE WHT/BLU WIRE YEL WIRE
