Manual a/c circuit for Pontiac GTO IV (2004-2006)

A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH DIODE A/C COMPRESSOR CLUTCH RELAY (MICRO) A/C IND A/C REQUEST A/C SWITCH BCM/ ENGINE BLK WIRE BLK/RED WIRE BLOWER FAN FUSE BLOWER FUSE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH) BLOWER MOTOR INLINE FUSE HOLDER BLOWER MOTOR RESISTOR ASSEMBLY (BELOW RIGHT SIDE OF DASH) BLOWER RELAY (MICRO) BLR MTR LOW CTRL BLU/WHT WIRE BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH) BRN/WHT WIRE CONTROL FUSE DATA LINK CONNECTOR (DLC) DEFOG IND DEFOG SWITCH 1 2 DEFOGGER SYSTEM ENGINE CONTROL MODULE ENGINE GROUND ENGINE SENSORS FUSE GRN WIRE GRY WIRE HEATED REAR WINDOW FUSE HIGH SPD COOL FAN HOT AT ALL TIMES HOT IN RUN OR START HVAC CONTROL ASSEMBLY (CENTER OF DASH, UNDER RADIO) LOW SPD COOL FAN LT GRN/BLK WIRE OF BATTERY) OFF ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRN WIRE PNK WIRE PNK/BLU WIRE QUARTER TRIM PANEL, NEAR SEAT BOTTOM) RAD FAN LARGE FUSE RAD FAN SMALL FUSE REAR DEFOG SW RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SEC REAR DEFOG SW UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) YEL WIRE YEL/BLK WIRE

A/C REFRIGERANT PRESSURE SENSOR (LEFT FRONT CORNER OF ENGINE COMPT) BLK WIRE BLK/RED WIRE BLOWER INHIBIT RELAY BLU/WHT WIRE BLU/YEL WIRE BRN/GRY WIRE CLU RLY CTRL COOLING FAN ASSEMBLY ECT SENSOR SIG ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT SIDE OF ENGINE, BELOW GENERATOR) GRN WIRE GRN/BLK WIRE GRY/BLK WIRE HEATED REAR WINDOW, HVAC, INSTRUMENTS FUSE HOT IN RUN OR START INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH) LARGE FAN LOW REF LT GRN/BLK WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRN WIRE ORG/YEL WIRE PNK/BLU WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT) PRESS SENS SIG RADIATOR FAN RELAY 2 RADIATOR FAN RELAY 3 RADIATOR FAN RELAY-1 SMALL ENGINE COOLING FAN) SMALL FAN TAN WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) UNDERHOOD FUSE PANEL) VOL (-) YEL WIRE
