Pontiac GTO IV (2004-2006) rear compt release actuator) Wiring diagram
This page shows the only wiring diagram for the component.rear compt release actuator), which is found in the car Pontiac GTO IV (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear compt release actuator) (1 of 1)
AJAR INDICATOR SWITCH
AUDIO AMPLIFIER
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DOOR OUTSIDE REARVIEW MIRROR SWITCH LOCK MASTER WINDOW SWITCH CYLINDER SWITCH
DRIVER DOOR LOCK
DRIVER DOOR LOCK ACTUATOR
DRIVER MEMORY SEAT MODULE SEAT BELT ALARM SWITCH
FROM BACK UP LIGHT LAMPS)
FROM FIGHT REAR TURN SIGNAL)
FROM RIGHT DOOR LOCK)
FROM SUBWOOFER AMPLIFIER)
FUEL PUMP, SENDER ASSEMBLY
LEFT BACK-UP LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT TAIL/ STOP LAMP
LEFT VANITY MIRROR LAMP
LICENSE LAMP
LOCK SWITCH
NCA WIRE
PANEL, BELOW QUARTER GLASS)
PASSENGER DOOR LOCK ACTUATOR
PASSENGER DOOR LOCK AJAR INDICATOR SWITCH
REAR COMPARTMENT LID RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE ACTUATOR DIODE
REAR COMPT RELEASE ACTUATOR)
RIGHT BACK-UP LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT SEAT MEMORY MODULE
RIGHT TAIL/ STOP LAMP
RIGHT VANITY MIRROR LAMP PASSENGER MEMORY SEAT MODULE
SUBWOOFER AMPLIFIER
TURN SIGNAL LAMP
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> REAR COMPT RELEASE ACTUATOR)
