Pontiac GTO IV (2004-2006) park lamps relay Wiring diagrams
This page contains all the electrical diagrams for the component. park lamps relay, in which he is found in the car Pontiac GTO IV (2004-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram park lamps relay (1 of 3)
AUTO
BACK-UP LAMPS CIRCUIT
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH)
BRN WIRE
BRN/WHT WIRE
FLASHER RELAY
GRY WIRE
HAZARD SWITCH
HDLMPS OFF
HDLMPS ON
HDLP RET
HEAD
HEADLAMP SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR ACC
HZRD SW SIG
INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH)
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT REAR TURN SIGNAL LAMP
LT BLU WIRE
OFF
ORG/ WIRE
PARK
PARK LAMP TURN LAMP
PARK LAMPS FUSE
PARK LAMPS RELAY
PPL
PRK LP RET
RED WIRE
RIGHT FRONT MARKER LAMP PARK LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT REAR TURN SIGNAL LAMP
SENSE
TURN LAMP
TURN SIGNALS, BACKUP LAMPS FUSE
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> PARK LAMPS RELAY
Wiring diagram park lamps relay (2 of 3)
ABS FUSE
ABS, TCS CONTROL MODULE FUSE
BATTERY
BCM/ENGINE RADIATOR FAN RELAY 3 (HIGH SPEED) CONTROLS FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
COOLING FAN ASSEMBLY
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LAMPS RELAY
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM)
ENGINE FUSE
FOG LAMP CANCEL RELAY
FOG LAMP RELAY
FROM ABS FUSE (DIAGRAM 1 OF 4)
FUEL PUMP FUSE
FUEL PUMP RELAY
FUSIBLE LINK
GENERATOR
HAZARD LAMPS FUSE
HAZARD/ THEFT INDICATOR RELAY
HEADLAMP RELAY (HIGH BEAM)
HEADLAMP RELAY (LOW BEAM)
INSTRUMENT FUSE PANEL)
INTERIOR ILLUMIN- ATION RELAY
INTERIOR ILLUMINATION FUSE
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HEADLAMP FUSE
LIGHTING FUSE
ORG/ WIRE
ORG/BLK WIRE
PARK LAMPS RELAY
POWERTRAIN INTERFACE MODULE
RAD FAN LARGE FUSE
RADIATOR FAN RELAY 1 (LOW SPEED)
RADIATOR FAN RELAY 2 (HIGH SPEED)
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP FUSE
STARTER
STOP LAMP SWITCH
STOP LAMPS FUSE PARK LAMPS FUSE
TO ENGINE CONTROL RELAY (DIAGRAM 3 OF 4)
TO ENGINE FUSE (DIAGRAM 1 OF 4)
TO MAIN FUSE (DIAGRAM 2 OF 4)
TRANSMISSION CONTROL MODULE (TCM) AMBIENT LIGHT SENSOR
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> PARK LAMPS RELAY
Wiring diagram park lamps relay (3 of 3)
AJAR SW SIG
BATTERY PANEL LAMPS SERIAL DATA BATTERY ACCESSORY
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH)
BRN/WHT WIRE
CHIME
COMPUTER DATA LINES SYSTEM
DOOR AJAR INDICATOR
DOOR AJAR SW
DRIVER DOOR LOCK AJAR INDICATOR SWITCH
GRN/WHT WIRE
GROUND
GRY/WHT WIRE
HDLMPS OFF
HDLMPS ON
HEADLAMP SWITCH
HEATED REAR WINDOW, HVAC, INSTRUMENTS FUSE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT W/ PARK LAMPS ON
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
INSTRUMENTS FUSE
INSTRUMENTS ILLUM FUSE
OFF PARK HEAD AUTO
ON LOCK OFF
ORG/ WIRE
ORG/WHT WIRE
ORG/YEL WIRE
PARK LAMPS FUSE
PARK LAMPS RELAY
PNK/BLU WIRE
PRK LP RET
SEAT BELT BUCKLE SWITCH
SEAT BELT INDICATOR
SEAT BELT SW-
WHT/RED WIRE
Go to component -> Warning systems circuit -> PARK LAMPS RELAY
