Pontiac GTO IV (2004-2006) high spd cool fan rel ctrl Wiring diagram
This page shows the only wiring diagram for the component.high spd cool fan rel ctrl, which is found in the car Pontiac GTO IV (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high spd cool fan rel ctrl (1 of 1)
BCM/ENGINE CONTROL FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH)
BRN/GRY WIRE
COOLING FAN ASSEMBLY
DATA LINK CONNECTOR (UNDER DASH, BELOW STEERING COLUMN)
ECT SENSOR SIGNAL
ENGINE CONTROL MODULE (ECM)
GRY/BLK WIRE
HIGH SPD COOL FAN REL CTRL
HOT AT ALL TIMES
LARGE FAN
LOW REF
LOW SPD COOL FAN REL CTRL
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/YEL WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF OF ENGINE COMPT)
RAD FAN LARGE FUSE
RAD FAN SMALL FUSE
RADIATOR FAN RELAY 2
RADIATOR FAN RELAY 3
RADIATOR FAN RELAY-1
SMALL ENGINE COOLING FAN)
SMALL FAN
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE PANEL)
YEL WIRE
Go to component -> Cooling fan circuit -> HIGH SPD COOL FAN REL CTRL
