Pontiac GTO IV (2004-2006) heated rear window, hvac, instruments fuse Wiring diagrams

A/C A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (MICRO) A/C IND A/C REFRIGERANT PRESSURE SENSOR (LEFT FRONT CORNER OF ENGINE COMPT) A/C REQUEST A/C SWITCH BLK/RED WIRE BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH) CLU RLY CTRL CLUTCH DIODE COMPRESSOR) COMPUTER DATA LINES SYSTEM ENGINE GROUND ENGINE SENSORS FUSE GRN WIRE GRN/BLK WIRE HEATED REAR WINDOW, HVAC, INSTRUMENTS FUSE HOT IN RUN OR START HVAC CONTROL ASSEMBLY (CENTER OF DASH, UNDER RADIO) INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH) LOW REF LT GRN/BLK WIRE PNK WIRE PNK/BLU WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT) PRESS SENS SIG RED/BLK WIRE RED/WHT WIRE SERIAL DATA TAN WIRE UART SERIAL DATA UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) VOL (-)

A/C LED IND A/C REQ SIG A/C SW ANT DFG ANTENNA SOLID STATE BLK WIRE BLU WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH) SECNDRY RR DFG SW SIG DEFOG LED DEFOG RELAY (MINI) DEFOG SW DFG HEATED REAR WINDOW FUSE HEATED REAR WINDOW, HVAC, INSTRUMENTS FUSE HOT AT ALL TIMES HOT IN RUN OR START HVAC CONTROL ASSEMBLY (CENTER OF DASH, UNDER RADIO) INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH) NCA WIRE ORG/ WIRE PNK WIRE PPL PPL/RED WIRE REAR WINDOW DEFOGGER GRID RADIO ANTENNA REAR WINDOW DEFOGGER, RADIO ANTENNA MODULE RED WIRE RR DFG SW SIG SIG SOUND SYSTEMS UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) WHT WIRE YEL/RED WIRE

A/C REFRIGERANT PRESSURE SENSOR (LEFT FRONT CORNER OF ENGINE COMPT) BLK WIRE BLK/RED WIRE BLOWER INHIBIT RELAY BLU/WHT WIRE BLU/YEL WIRE BRN/GRY WIRE CLU RLY CTRL COOLING FAN ASSEMBLY ECT SENSOR SIG ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT SIDE OF ENGINE, BELOW GENERATOR) GRN WIRE GRN/BLK WIRE GRY/BLK WIRE HEATED REAR WINDOW, HVAC, INSTRUMENTS FUSE HOT IN RUN OR START INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH) LARGE FAN LOW REF LT GRN/BLK WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRN WIRE ORG/YEL WIRE PNK/BLU WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT) PRESS SENS SIG RADIATOR FAN RELAY 2 RADIATOR FAN RELAY 3 RADIATOR FAN RELAY-1 SMALL ENGINE COOLING FAN) SMALL FAN TAN WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) UNDERHOOD FUSE PANEL) VOL (-) YEL WIRE

AJAR SW SIG BATTERY PANEL LAMPS SERIAL DATA BATTERY ACCESSORY BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH) BRN/WHT WIRE CHIME COMPUTER DATA LINES SYSTEM DOOR AJAR INDICATOR DOOR AJAR SW DRIVER DOOR LOCK AJAR INDICATOR SWITCH GRN/WHT WIRE GROUND GRY/WHT WIRE HDLMPS OFF HDLMPS ON HEADLAMP SWITCH HEATED REAR WINDOW, HVAC, INSTRUMENTS FUSE HOT AT ALL TIMES HOT IN RUN OR START HOT W/ PARK LAMPS ON IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH) INSTRUMENTS FUSE INSTRUMENTS ILLUM FUSE OFF PARK HEAD AUTO ON LOCK OFF ORG/ WIRE ORG/WHT WIRE ORG/YEL WIRE PARK LAMPS FUSE PARK LAMPS RELAY PNK/BLU WIRE PRK LP RET SEAT BELT BUCKLE SWITCH SEAT BELT INDICATOR SEAT BELT SW- WHT/RED WIRE
