Pontiac GTO IV (2004-2006) front wiper relay Wiring diagram
This page shows the only wiring diagram for the component.front wiper relay, which is found in the car Pontiac GTO IV (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front wiper relay (1 of 1)
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH)
BRN/WHT WIRE
FROM BCM)
FRONT WASHER SWITCH
FRONT WASHER, WIPER CIRCUIT BREAKER
FRONT WIPER RELAY
FRONT WIPER/ WASHER SWITCH
GRN WIRE
GRY/BLK WIRE
GRY/RED WIRE
HIGH OFF
HOT IN ACC OR RUN
IGN
INSTRUMENT PANEL FUSE BLOCK (BELOW LEFT END OF DASH)
INT INT LOW LOW
INT LOW
LOW HIGH
LT BLU WIRE
OFF
OFF HIGH HIGH
OFF/ HIGH
PARK
RTN
SPLICE PACK
WHT/BLU WIRE
WINDSHIELD WASHER MOTOR (LEFT FRONT OF ENGINE COMPT)
WINDSHIELD WASHER PUMP CONTROL
WINDSHIELD WIPER DWELL MODULE
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER SWITCH SIGNAL 1
WINDSHIELD WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit -> FRONT WIPER RELAY
