Pontiac GTO IV (2004-2006) from turn signal multi function switch) Wiring diagram
This page shows the only wiring diagram for the component.from turn signal multi function switch), which is found in the car Pontiac GTO IV (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from turn signal multi function switch) (1 of 1)
ACCESSORY POWER OUTLET
BATTERY
BLK WIRE
BLK/WHT WIRE
BLOWER INHIBIT RELAY
BLOWER RELAY
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CONSOLE COMPARTMENT SWITCH
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LAMPS RELAY
ECM/TCM CONTROL RELAY 1
ECM/TCM CONTROL RELAY 2
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
FROM CRUISE CONTROL MODULE)
FROM LEFT HORN)
FROM TURN SIGNAL MULTI FUNCTION SWITCH)
FROM UNDERHOOD FUSE BLOCK
FRONT CIGAR LIGHTER
FUEL PUMP RELAY FOG LAMP
GRN WIRE
HEADLAMP RELAY (HIGH BEAM)
HEADLAMP RELAY (LOW BEAM)
HORN 1
HORN 2
IGNITION CONTROL RELAY
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT MARKER LIGHT)
ORG/ WIRE
RADIATOR FAN RELAY 1 SHIFTLOCK CONTROL RELAY
RADIATOR FAN RELAY 2
RADIO
REAR CIGAR LIGHTER
REAR COMPARTMENT LID RELEASE SWITCH
RED WIRE
RELAY
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
UNDERHOOD FUSE BLOCK
WHT WIRE
WINDSHIELD WIPER DWELL MODULE
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> FROM TURN SIGNAL MULTI FUNCTION SWITCH)
