Pontiac GTO IV (2004-2006) from right headlight) Wiring diagram
This page shows the only wiring diagram for the component.from right headlight), which is found in the car Pontiac GTO IV (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from right headlight) (1 of 1)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
DAYTIME RUNNING LAMPS RELAY (MICRO)
DRL RESISTOR
FOG LAMP CANCEL RELAY (MICRO)
FOG LAMP RELAY (MICRO)
FROM LEFT FOG LIGHT)
FROM LEFT HEADLIGHT)
FROM RIGHT HEADLIGHT)
GRN WIRE
HEADLAMP HIGH BEAM RELAY (MICRO)
HEADLAMP LOW BEAM RELAY (MICRO)
HI-BM
HI-RET
HOT AT ALL TIMES
LEFT FRONT FOG LAMP
LEFT HEAD- LAMP HI-BM
LH HEADLAMP FUSE
LIGHTING FUSE
LO-BM
LO-RET
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PPL
PPL/RED WIRE
RED WIRE
RH HEADLAMP FUSE
RIGHT FRONT FOG LAMP
RIGHT HEAD- LAMP
TAN WIRE
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE PANEL)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlights circuit (2 of 2) -> FROM RIGHT HEADLIGHT)
