Pontiac GTO IV (2004-2006) engine control relay auto trans fuse Wiring diagram
This page shows the only wiring diagram for the component.engine control relay auto trans fuse, which is found in the car Pontiac GTO IV (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine control relay auto trans fuse (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/T M/T
BANK 1 SENSOR 2
BANK 2 SENSOR 1 BANK 2 SENSOR 2 BANK 1 SENSOR 1
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BODY CONTROL MODULE (BCM)
BRN WIRE
DK GRN WIRE
ECM SIGNAL FUSE
ECM/TCM CONTROL RELAY 2 ECM/TCM CONTROL RELAY 1
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL RELAY AUTO TRANS FUSE
ENGINE SENSORS FUSE
FROM SPLICE
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR ENGINE CONTROL MODULE (ECM) STOP LAMP SWITCH
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LOCK OFF
LT BLU WIRE
OIL PRESSURE SENSOR) PNK/ PNK PNK WIRE
ORG/ WIRE
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/ PNK/ SKIP SHIFT SOLENOID) WIRE
POWERTRAIN INTERFACE MODULE (PIM)
PPL
RED WIRE
RELAY
REVERSE LOCKOUT SOLENOID AUTOMATIC TRANSMISSION
RUN WIRE
SHIFTLOCK CONTROL SOLENOID ASSEMBLY
TAN WIRE
TO IGNITION CONTROL RELAY (DIAGRAM 4 OF 4)
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> ENGINE CONTROL RELAY AUTO TRANS FUSE
