Pontiac GTO IV (2004-2006) body control module radio Wiring diagram
This page shows the only wiring diagram for the component.body control module radio, which is found in the car Pontiac GTO IV (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body control module radio (1 of 1)
ACCESSORY CONTROL RELAY
ACCESSORY POWER OUTLET
AUDIO AMPLIFIER
BLK WIRE
BLOWER FAN FUSE
BLOWER MOTOR
BLOWER MOTOR INLINE FUSE HOLDER BLOWER FUSE
BLOWER RELAY
BLU WIRE
BODY CONTROL MODULE
BODY CONTROL MODULE RADIO
BRN WIRE
CELLULAR PHONE CONNECTOR
DEFOG RELAY
DRIVER'S MEMORY SEAT MODULE
FROM ENGINE FUSE (DIAGRAM 1 OF 4)
FUEL DOOR RELEASE ACTUATOR
GRN WIRE
HEATED REAR WINDOW FUSE
HORN FUSE
HORN RELAY
IGNITION SWITCH FUSE
INSTRUMENT FUSE PANEL)
INSTRUMENT PANEL CLUSTER AUXILIARY GAUGES (NOT USED)
INSTRUMENTS FUSE SPARE FUSE
MAIN FUSE
ORG/ WIRE
PASSENGER'S MEMORY SEAT MODULE
PHONE CONNECTOR)
PNK WIRE
POWER DOOR LOCKS, THEFT, HORN POWER WINDOWS FUSE
POWER SEAT
POWER SEATS CIRCUIT BREAKER
POWER WINDOW RELAY
POWER WINDOWS CIRCUIT BREAKER
PPL
RAD FAN SMALL FUSE
RADIATOR FAN RELAY 3 (HIGH SPEED)
RADIO
RADIO CELLULAR PHONE FUSE
RED WIRE
RELAY
SOCKET FUSE
SPARE FUSE
SPARE FUSE FRONT WASHER, WIPER CIRCUIT BREAKER
SUB WOOFER AMPLIFIER FUSE
TO ECM SIGNAL FUSE (DIAGRAM 3 OF 4)
TO IGNITION CONTROL RELAY (DIAGRAM 4 OF 4)
TO IGNITION SWITCH (DIAGRAM 3 OF 4)
UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE PANEL)
WHT WIRE
WINDSHIELD WIPER MOTOR WINDSHIELD WIPER/ WASHER SWITCH BODY CONTROL MODULE (BCM)
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> BODY CONTROL MODULE RADIO
