Pontiac G6 I (2004-2009) Charging circuit

BATTERY BLK WIRE BLU WIRE CHARGE INDICATOR COMPUTER DATA LINES SYSTEM DK GRN WIRE ECM/PCM SERIAL DATA IGN ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK (12 GA- GENERATOR GENERATOR FIELD DUTY CYCLE SIGNAL GENERATOR TURN ON SIGNAL GRY WIRE HIGH SPEED GMLAN SERIAL DATA BUS + INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOW SPEED GMLAN SERIAL DATA LOW SPEED GMLAN SERIAL DATA ORG/ WIRE POWER DISTRIBUTION SYSTEM RED WIRE STARTER TAN WIRE TAN/BLK WIRE
