3.5l vin n, back-up lamps circuit for Pontiac G6 I (2004-2009)
3.5l vin n, back-up lamps circuit
2.4L 3.5L
28 27 53 33 HI SPD SER DATA + HI SPD SER DATA -
29 46 TRS SIG A TRS SIG B
38 37 HI SPD SER DATA + HI SPD SER DATA -
B/U LP RELAY 33
BCK/UP LAMPS FUSE 17
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE CONVERTIBLE, SEDAN
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
HI SPD SER DATA + HI SPD SER DATA -
HOT AT ALL TIMES
LEFT BACK-UP LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP
LT BLU WIRE
LT GRN WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (BELOW MASTER CYLINDER, ON TRANSMISSION)
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPT, BEHIND LEFT REAR WHEEL WELL)
REV LMP RLY CTRL
RIGHT BACK-UP LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL MODULE (TCM) (LEFT OF ENGINE COMPARTMENT, NEAR STRUT TOWER)
WHT WIRE
YEL WIRE
