3.9l vin 1, cruise control circuit for Pontiac G6 I (2004-2009)

1 2 3 PNK WIRE 3 SPOKE 3.5L/3.9L 5 VOLT REF BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH) BRAKE PEDAL POSITION SENS SIG BRN WIRE CLUTCH PEDAL POSITION (CPP) SWITCH (3.9L M/T) (ABOVE CLUTCH PEDAL) COMPUTER DATA LINES SYSTEM CRUISE CTRL CANCEL SIG CRUISE CTRL SW SIG CRUISE INDICATOR DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ECM/ PCM GMLAN GROUND GRY WIRE GRY/BLK WIRE HIGH SPD GMLAN SERIAL DATA BUS - HOT W/ RUN/CRANK RELAY ENERGIZED IBCM (RUN/CRANK) FUSE IGN INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOW REF LOW SPEED GMLAN SERIAL DATA LT GRN WIRE PNK WIRE PPL PPL VSS LOW SIG REAR FUSE BLOCK (LEFT SIDE OF REAR COMPARTMENT, BEHIND LEFT REAR WHEELWELL) RUN/CRANK FUSE STOP LAMP SW SIG TAN WIRE TAN/BLK WIRE TRANSMISSION CONTROL MODULE (TCM) (LEFT OF ENGINE COMPT, NEAR STRUT TOWER) UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (3.9L M/T) (ON MANUAL TRANSMISSION) VEHICLE SPEED SENSOR (VSS) (A/T) VEHICLE SPEED SIGNAL VSS HIGH SIG WHT WIRE YEL WIRE

1 2 3 PNK WIRE 3.5L/3.9L 3.6L 3.9L M/T ACCELERATOR PEDAL POSITION (APP) SENSOR (ATTACHED TO ACCELERATOR PEDAL) APP SENS 1 SIG APP SENS 2 SIG APP SENSOR 1 APP SENSOR 2 BLK/WHT WIRE BRN WIRE CPP SW CRUISE CANCEL SWITCH CRUISE ON/OFF SWITCH DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HIGH SIG VSS LEFT STEERING WHEEL CONTROLS LOW REF LOW SIG VSS LT BLU WIRE LT GRN WIRE M/T 3.9L PNK 3 SPOKE WIRE PNK 4 SPOKE WIRE PNK WIRE PPL RES+ RIGHT STEERING WHEEL CONTROLS SET- SIG STOP LAMP SW SIG TAC MOTOR CTRL 1 TAC MOTOR CTRL 2 TAN WIRE THROTTLE ACTUATOR CONTROL (TAC) MODULE TP SENS 1 SIG TP SENS 2 SIG VEHICLE SPD SIG W/O ACCESSORY STEERING WHEEL CONTROL W/ ACCESSORY STEERING WHEEL CONTROL WHT WIRE WHT/BLK WIRE YEL WIRE
