Pontiac G6 I (2004-2009) run/crank relay 32 frt fog relay 36 Wiring diagram
This page shows the only wiring diagram for the component.run/crank relay 32 frt fog relay 36, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram run/crank relay 32 frt fog relay 36 (1 of 1)
18 49 (3.6L) (2.4L, 3.9L)
2.4L/3.9L
3 SPOKE
4 SPOKE
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RIGHT COOLING FAN
A/T
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) TURN SIGNAL/ MULTIFUNCTION SWITCH HVAC CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
COOL/FAN SER/PAR RELAY 29
DATA LINK CONNECTOR (DLC)
ENGINE CONTROL MODULE (ECM)
EXCEPT 2.4L 2.4L
GRN WIRE
HORN SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
INTAKE MANIFOLD TUNING (IMT) VALVE SOLENOID
INTERNAL MODE SWITCH (IMS)
LEFT BACK-UP LAMP
LEFT REAR MARKER LAMP LEFT TAIL/ STOP, TURN SIGNAL LAMP
LEFT STEERING WHEEL CONTROLS
LEFT STEERING WHEEL CONTROLS RIGHT STEERING WHEEL CONTROLS
LICENSE LAMP
LT LT
MANUAL A/C AUTOMATIC A/C 3 4
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
NCA WIRE
POWER STEERING CONTROL MODULE
RADIO
RELAY 31
RIGHT COOLING FAN
RUN/CRANK RELAY 32 FRT FOG RELAY 36
THEFT DETERRENT CONTROL MODULE
TRANSMISSION CONTROL MODULE (TCM)
W/ CRUISE CONTROL
W/ STEERING WHEEL ACCESSORY CONTROL W/O STEERING WHEEL ACCESSORY CONTROL
W/O CRUISE CONTROL
WHT WIRE
WINDSHIELD WIPER MOTOR ASSEMBLY
WIPER 1 RELAY 39
WIPER 2 RELAY 40
Go to component -> Ground distribution circuit (1 of 3) -> RUN/CRANK RELAY 32 FRT FOG RELAY 36
