Pontiac G6 I (2004-2009) rt ast mtr cntl lt ast mtr cntl Wiring diagram
This page shows the only wiring diagram for the component.rt ast mtr cntl lt ast mtr cntl, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rt ast mtr cntl lt ast mtr cntl (1 of 1)
1 2 3 4 5 6 7 8 SERIAL DATA + SERIAL DATA -
B+ GROUND
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
EPS FUSE
EPS FUSE 41
HOT AT ALL TIMES
HOT IN RUN OR START
LOGIC
PNK IGN 1 VOLT WIRE
PNK WIRE
POSITION
POWER STEERING MOTOR
PPL
RED WIRE
RED/BLK WIRE
RT AST MTR CNTL LT AST MTR CNTL
SERIAL DATA (-) SERIAL DATA (+)
STEER SHAFT TOR SENS SIG 1
STEER WHEEL POS SEN 5 VOLT REF STEER SHAFT TOR SENS SIG 2
STEER WHEEL POS SEN LOW REF
STEER WHEEL POS SEN SIGNAL 1
STEER WHEEL POS SEN SIGNAL 2
STEERING COLUMN ASSEMBLY
TAN WIRE
TAN/BLK WIRE
TORQUE
TORQUE/ POSITION SENSOR
UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Electronic power steering circuit -> RT AST MTR CNTL LT AST MTR CNTL
