Pontiac G6 I (2004-2009) right front speaker assembly Wiring diagram
This page shows the only wiring diagram for the component.right front speaker assembly, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front speaker assembly (1 of 1)
1 2 3 4 5 6 7 8 BATTERY GROUND RR SUB SPKR OUT (-) RR SUB SPKR OUT (+)
AUDIO AMP FUSE 13
AUDIO AMPLIFIER (RIGHT SIDE OF REAR COMPARTMENT)
BLK WIRE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR TWEETER SPEAKER
LEFT FRONT SPEAKER
LEFT FRONT SPEAKER ASSEMBLY
LEFT FRONT SUBWOOFER SPEAKER
LEFT REAR DOOR SPEAKER
LF SUB SPKR OUT (-) LF SUB SPKR OUT (+)
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPARTMENT, BEHIND LEFT REAR WHEEL WELL)
RED WIRE
RED/WHT WIRE
RF SPEAKER OUT (-) RF SPEAKER OUT (+) LF SPEAKER OUT (+) LF SPEAKER OUT (-)
RIGHT FRONT DOOR TWEETER SPEAKER
RIGHT FRONT SPEAKER
RIGHT FRONT SPEAKER ASSEMBLY
RIGHT FRONT SUBWOOFER SPEAKER
RIGHT REAR DOOR SPEAKER
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> 8-speaker system circuit, convertible (2 of 2) -> RIGHT FRONT SPEAKER ASSEMBLY
