Pontiac G6 I (2004-2009) rear compartment partition position switch Wiring diagram
This page shows the only wiring diagram for the component.rear compartment partition position switch, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear compartment partition position switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
DOOR
FOLDING TOP OPEN/ CLOSE SWITCH
FUEL/PUMP RELAY 37
GRN WIRE
IGNITION COIL/ MODULE 1 IGNITION COIL/ MODULE 3
IGNITION COIL/ MODULE 5 IGNITION COIL/ MODULE 2
IGNITION COIL/ MODULE 6 IGNITION COIL/ MODULE 4
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INSIDE REARVIEW MIRROR
LEFT FOLDING TOP FRONT LOCATION PIN GUIDE
LEFT VANITY MIRROR LAMP
LT LT LT LT
NCA WIRE
REAR COMPARTMENT LID LATCH
REAR COMPARTMENT LID RELEASE SWITCH
REAR COMPARTMENT PARTITION POSITION SWITCH
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPARTMENT, BEHIND LEFT REAR WHEEL WELL)
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPT, BEHIND LEFT REAR WHEEL WELL)
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT REAR MARKER LAMP RIGHT BACK-UP LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP
RIGHT VANITY MIRROR LAMP
RR DEFOG RELAY 26
SUNROOF CONTROL MODULE SUNROOF SHADE MODULE SUNROOF SHADE SWITCH SUNROOF SWITCH
W/ INSIDE SUNSHADE MIRROR
W/ ONSTAR
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> REAR COMPARTMENT PARTITION POSITION SWITCH
