Pontiac G6 I (2004-2009) passenger heated seat switch passenger heated seat control module Wiring diagram
This page shows the only wiring diagram for the component.passenger heated seat switch passenger heated seat control module, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger heated seat switch passenger heated seat control module (1 of 1)
A/C CLU FUSE 1
A/C CLUTCH RELAY 34
ACCESSORY RELAY
BLK WIRE
BODY CONTROL MODULE (BCM)
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRN WIRE
C/FAN 1 FUSE 17
COOLING FAN 1 RELAY 28
COOLING SER/PAR RELAY 29
COUPE
COUPE, SEDAN
DOOR LOCK FUSE
DRIVER HEATED SEAT CONTROL MODULE DRIVER HEATED SEAT SWITCH
DRIVER WINDOW SWITCH
FROM EPS FUSE 41 (DIAGRAM 1 OF 5)
IBCM 2 FUSE 25
LOGIC
PASSENGER HEATED SEAT SWITCH PASSENGER HEATED SEAT CONTROL MODULE
PASSENGER WINDOW SWITCH
POWER WINDOWS FUSE WIPER SW FUSE
POWERTRAIN RELAY 33
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPT, BEHIND LEFT REAR WHEEL WELL)
RED WIRE
RLY CTRL LOGIC
ROOF/HEAT SEAT FUSE
SEDAN
SUNROOF CONTROL MODULE
TO IBCM 1 FUSE 20 (DIAGRAM 3 OF 5)
TO INTERIOR LIGHTS FUSE (DIAGRAM 4 OF 5)
UNDER- HOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT)
W/ PANORAMIC SUNROOF
W/ STANDARD SUNROOF
WINDSHIELD WIPER/ WASHER SWITCH DRIVER WINDOW SWITCH
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> PASSENGER HEATED SEAT SWITCH PASSENGER HEATED SEAT CONTROL MODULE
