Pontiac G6 I (2004-2009) passenger door lock switch passenger window motor Wiring diagram
This page shows the only wiring diagram for the component.passenger door lock switch passenger window motor, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger door lock switch passenger window motor (1 of 1)
A/T SHIFT LOCK CONTROL ASSEMBLY
AUXILIARY POWER OUTLET
BLK WIRE
BODY CONTROL MODULE (BCM) I/P DIMMER SWITCH
CIGAR LIGHTER
CONVERTIBLE, SEDAN COUPE
COUPE/CONVERTIBLE
DATA LINK CONNECTOR (DLC)
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK SWITCH
DRIVER HEATED SEAT CONTROL MODULE PASSENGER HEATED SEAT SWITCH
DRIVER HEATED SEAT SWITCH
DRIVER SEAT ADJUSTER SWITCH
DRIVER WINDOW SWITCH PASSENGER WINDOW SWITCH
HAZARD SWITCH
HORN ASSEMBLY
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INTERIOR REAR COMPART- MENT LID RELEASE SWITCH
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT HEADLAMP HIGH BEAM
LEFT HEADLAMP LOW BEAM
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER DOOR LATCH ASSEMBLY FUEL PUMP, SENDER ASSEMBLY
PASSENGER DOOR LOCK SWITCH PASSENGER WINDOW MOTOR
PASSENGER HEATED SEAT CONTROL MODULE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT HEADLAMP HIGH BEAM
RIGHT HEADLAMP LOW BEAM
W/ 2-WAY VERTICAL DRIVER POWER SEAT W/ MULTI-DIRECTIONAL DRIVER POWER SEAT
W/ FRONT HEATER SEATS
WIND- SHIELD WASHER FLUID LEVEL SWITCH
WIND- SHIELD WASHER FLUID PUMP
Go to component -> Ground distribution circuit (2 of 3) -> PASSENGER DOOR LOCK SWITCH PASSENGER WINDOW MOTOR
