Pontiac G6 I (2004-2009) (on right front of passenger compartment, behind right front kick panel, Wiring diagram
This page shows the only wiring diagram for the component.(on right front of passenger compartment, behind right front kick panel,, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (on right front of passenger compartment, behind right front kick panel, (1 of 1)
5 VOLT REFERENCE LOW REFERENCE
A/T SHIFT LOCK CONTROL ASSEMBLY
A/T SHIFT LOCK CONTROL SOLENOID
A/T SHIFT LOCK CTRL SOLENOID SUPPLY VOLTAGE
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRAKE PEDAL POSITION SENSOR (IN RIGHT SIDE OF BRAKE PEDAL BRACKET)
BRAKE PEDAL POSITION SENSOR SIGNAL
BRN WIRE
DK GRN WIRE
DOOR
DOOR LOCK FUSE
GROUND
HOT AT ALL TIMES
INTERIOR LIGHTS FUSE
LOGIC
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> (ON RIGHT FRONT OF PASSENGER COMPARTMENT, BEHIND RIGHT FRONT KICK PANEL,
