Pontiac G6 I (2004-2009) left right front front inlet outlet Wiring diagram
This page shows the only wiring diagram for the component.left right front front inlet outlet, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left right front front inlet outlet (1 of 1)
ABS FUSE 15
ABS FUSE 24
B+ PUMP MOTOR CONTROL
BAT BAT IGN 1 VOLTAGE
BLK WIRE
BRAKE PRESSURE MODULATOR VALVE (BPMV)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/ RUN/ CRANK RELAY ENERGIZED
LEFT FRONT INLET
LEFT FRONT ISO- LATION
LEFT FRONT PRIME
LEFT FRONT WHEEL SPEED SENSOR (WSS) (IN LEFT FRONT WHEEL HUB)
LEFT REAR INLET
LEFT REAR WHEEL SPEED SENSOR (WSS) (IN LEFT REAR WHEEL HUB)
LEFT RIGHT FRONT FRONT INLET OUTLET
LOW REF
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PPL
PPL 1 2
PUMP MOTOR
RED/BLK WIRE
RIGHT FRONT ISO- LATION
RIGHT FRONT OUTLET
RIGHT FRONT PRIME
RIGHT FRONT WHEEL SPEED SENSOR (WSS) (IN RIGHT FRONT WHEEL HUB)
RIGHT LEFT REAR INLET REAR OUTLET
RIGHT REAR OUTLET
RIGHT REAR WHEEL SPEED SENSOR (WSS) (IN RIGHT REAR WHEEL HUB)
SOL VLV CONTROL
SOLENOID VALVES
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT)
W/ AUTOMATIC ELECTRONIC CONTROLLED RIDE, HANDLING
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> LEFT RIGHT FRONT FRONT INLET OUTLET
